Spitfire Aluminium Boat Trailer 700 Series 2000kg

Spitfire Aluminium Boat Trailer 700 Series 2000kg

$13,995.00
Boat Trailer (Aluminium & Stainless Steel) 7m Dual Axle 2000kg GVM, suits boats from 5.8 – 6.5m Specifications Full Alloy Bolted S/Steel 316 Trailer Torsion Axle Deemaxx Brakes Length 7m 2000kg GVM 1000kg Stainless Steel Winch Alloy Wheels 185R14

High quality Australian designed and NZ built aluminium and stainless steel boat trailer.

Drive-Away, ready for local rego.

Prices displayed include GST and are indicative only. Final pricing is subject to a formal quote.

Included Trailer features & Benefits

Tough, Anodised, Low Profile 6061-T6 Aluminium Alloy Chassis
Stainless Steel 316 fixtures & fittings
Stainless Steel 316 winch
DEEMAXX hydraulic Brakes
Combination of HDPE bunks and rollers for full boat support
High performance Glide-on keel slides and rear centring VEE
Alloy Rims & Heavy duty tyres matched to the maximum Load
Maintenance-free galvanised Torsion type axles for superior towing stability
Hydraulic disc brakes connected by stainless braided hose
LED tail lights with reverse lights
LED clearance lights
EZ-Lube Hub greasing system
Heavy duty top-wind 10″ jockey wheel
Load carrying checker-plate mudguards and steps for easy boat access
Warranty: 10 years on chassis, 2 years on genuine Spitfire components

Description

High quality Australian designed and NZ built aluminium and stainless steel boat trailer.

Drive-Away, ready for local rego.

Prices displayed include GST and are indicative only. Final pricing is subject to a formal quote.

Included Trailer features & Benefits

Tough, Anodised, Low Profile 6061-T6 Aluminium Alloy Chassis
Stainless Steel 316 fixtures & fittings
Stainless Steel 316 winch
DEEMAXX hydraulic Brakes
Combination of HDPE bunks and rollers for full boat support
High performance Glide-on keel slides and rear centring VEE
Alloy Rims & Heavy duty tyres matched to the maximum Load
Maintenance-free galvanised Torsion type axles for superior towing stability
Hydraulic disc brakes connected by stainless braided hose
LED tail lights with reverse lights
LED clearance lights
EZ-Lube Hub greasing system
Heavy duty top-wind 10″ jockey wheel
Load carrying checker-plate mudguards and steps for easy boat access
Warranty: 10 years on chassis, 2 years on genuine Spitfire components

Specifications

Model 700-2000
Build variations Up to 2200kg ATM
Hull/Boat types F/Glass & Ally mono hulls, Plate hulls, CAT
Max Boat kg (based on min Tow Ball kg) 1570
Approx Trailer Tare kg 470
Min Tow Ball kg 160
ATM / GTM kg 2000
Winch Rating & Gearing S/Steel 316 – 1000kg / 3 Spd
Chassis Rating kg 3500
Wheel Size 14″ Alloy / 185R14LT
Chassis Width (mm) 2495
Chassis Length (mm), excl tow coupling 7000
Keel height off ground (mm) 420
Width between guards (mm) 1950
Jockey Wheel 10″, Heavy Zinc, Top-Wind
Construction Bolted / No chassis welds
Design & Build Standards FEA / MVA1989-VSB1
